WP4R-B
Remote source and volume control
Black
Black
The WP4R wall panel is a 4 button controller with volume control knob.
Each button can be configured in software to provide a wide range of actions including source selection, volume control, muting, preset activation and more.
The WP4R has LED button status indicators and ample button label space. Connect to any Australian Monitor product with an accessory port using Cat5 cabling.
The wall panel can also be optionally colour customised using HPM® VIVO™ cover plates to create a unique look for each installation.
-
• 4 programmable buttons and dedicated volume control knob with mute push button
• Volume level meter
• Euroblock cable termination
• Customisable colour scheme using HPM® VIVO™ cover plates
• Also available in White, WP4R-W
CUSTOMISE THE LOOK WITH HPM® VIVO™ COVER PLATES
The WP4R is compatible with HPM® VIVO™ cover plates allowing up to 13 additional colour options to be created.
Simply replace the included cover plate with the alternative colour desired for a unique colour solution.
-
Function/s 4 Button and Volume Knob Output/s Euroblock Country Format AU/NZ Power Rating N/A Colour Black THD+N N/A Warranty 5 years Signal to Noise Ratio N/A Input Voltage 15-24Vdc Product Dimensions
(W x D x H)82mm x 121mm x 45mm Shipping Dimensions
(W x D x H)156mm x 132mm x 101mm Net Weight Shipping Weight 0.2 Kg GTIN EAN 9323383020412 -
