XRS6ODV
XRS6ODV Rear Label

XRS6ODVB

6 inch Passive Speaker
IP44 Rated, 80W, Black

The XRS6ODV is a weatherproof 6" Woofer and 1" HF driver in our XDS outdoor moulded range of speakers, which comes complete with a U bracket for installation.

Quantity must be 1 or more


  • • 6" Woofer, 1" HF compression driver
    • 90°x 60° dispersion pattern
    • Inbuilt transformer with tappings at 7.5, 15, 30 and 60 watts @ 70V/100V and 8 ohm bypass.
    • Frequency response 95 Hz - 18 kHz
    • Max SPL 117 dB
    • Sensitivity at 1w/1m is 92 dB
    • IP44 rated
    • Captive flylead
    • U bracket included
    • 6 x M8 eye bolt points
  • Form Factor Box Max Continuous Power 80W
    Tappings 60W-30W-15W-7.5W-8 Ohm Max Program Power 160W
    IP Rating IP44 Max Peak Power 320W
    EASE Model No SPL 1W/1m 92dB
    Powered Passive Max SPL RMS 111dB
    Driver Diameter 6" & 1" Max SPL Peak 117dB
    Colour Black Frequency Response (-3dB) 95Hz - 18kHz
    Warranty 5 years Dispersion 90 x 60deg
    Product Dimensions
    (W x D x H)
    225mm x 200mm x 325mm Shipping Dimensions
    (W x D x H)
    260mm x 260mm x 390mm
    Net Weight 7 Kg Shipping Weight 8.2 Kg
    GTIN EAN 9323383012714
  • XRS6ODVB Manual
